WEX Medical
1 / 5
| Model NO. | HCCA |
| Type | PVD Vacuum Coating Machine |
| Coating | Vacuum Coating |
| Substrate | Glass |
| Certification | CE, ISO |
| Condition | New |
| Technology | Arc Ion Plating |
| Coating Color | Gold, Rosegold, Silver, Black, Blue, Rainbow, etc |
| Control Mode | PLC Touch Screen |
| Eco-Friendly | No Heavy Metals, No Harmful Chemicals |
This equipment is based on cold cathode self-sustaining arc discharge plasma evaporation and ionization of plating materials, combined with pulse bias technology to improve the energy and activity of deposited particles and enhance the performance of the film. It is an efficient and pollution-free ion coating equipment, which has the advantages of fast deposition speed, high ionization rate, large ion energy, simple equipment operation, low cost and large production capacity.
The film produced has rich color, uniform appearance, wear resistance, corrosion resistance, high temperature resistance, and excellent adhesion that is resistant to fading.
| Mode | HCCA-1618 | HCCA-1619 | HCCA-1820 | HCCA-2020 |
|---|---|---|---|---|
| Size(mm) | 1600x1800 | 1600x1900 | 1800x1200 | 2000x2000 |
| Note: Customization available based on requirements. | ||||
Elevate your glassware with PVD decoration. Common applications include: sealed cans, candle cups, water cups, coffee pots, tea sets, vases, fruit platters, wine bottles, and exquisite crystal perfume bottles.
As a global supplier of vacuum application solutions, we specialize in the research, development, production, and sales of optical coating equipment, functional coating equipment, and decorative coating equipment. With a strong focus on PVD and ALD technologies, we provide industry-leading machinery for various sectors including automotive, decorative, and functional industries.
Publicly listed vacuum technology leader with proven market performance.
4 high-tech labs and over 150 patents in optical and functional materials.
Customizable logo, color, size, voltage, and core components.
The HCCA series is primarily designed for glass substrates, including glassware like bottles, cups, vases, and crystal perfume containers.
It offers fast deposition speeds, high ionization rates, and large ion energy, resulting in excellent film adhesion and high production capacity.
Yes, the PVD process is a clean alternative to traditional electroplating or lacquering as it uses no heavy metals or harmful chemicals.
Yes, the machine can produce a wide range of colors including Gold, Rose Gold, Silver, Black, Blue, and even Rainbow or gradient effects.
Absolutely. We offer customization for machine size, voltage, chamber configuration (vertical or horizontal), and core components to fit your production needs.
We provide a 24-hour rapid response technical service team and have a professional group of overseas engineers for installation, training, and maintenance.
